The process of steam generation in traditional steam equipment is water storage – heating – water boiling – steam generation. Speed-energy steam energy USES its own“ direct-current steam generation technology”, Steam is produced instantly as soon as the tap water flows through the heat exchanger. The realization of 5 seconds of steam, not only save energy, but also improve the steam generation speed, and greatly reduce heat loss.
Send InquiryLeway Speed-energy steam can adopt the integrated technology of condensation and steam generation. After the high-temperature flue gas is absorbed and utilized by the specially designed secondary heat recovery device, the thermal efficiency of the product can be effectively improved and the exhaust temperature can be reduced at the same time. Verified by the national authority， the exhaust temperature can be as low as 53℃, and PVC exhaust pipes can be used for installation, thus reducing investment and operating costs.
The first capital low emission environmental protection technology
The speed-energy steam can adopt the unique green structure, which makes the emission of the product far better than the national standard, especially in the control of carbon, nitrogen, and sulfur emission. Pour into special emission control technology, no fear of third-party environmental protection testing, to realize the solemn commitment of true low carbon + true low nitrogen.
Traditional steam generating equipment or steam boiler realizes periodic steam supply through periodic sectional steam heating so that the water storage temperature reaches a predetermined standard. The specially designed stainless steel heat exchanger is adopted by our company to greatly improve the heat exchange performance. Meanwhile, the surface of the heat exchanger is specially treated, which can effectively prevent corrosion and carbonization, and maintain long-term heat exchange efficiency.
New built-in pump connection technology. After rigorous calculation and hundreds of conquering tests, we carefully select booster pumps with matching performance for each set of equipment, so that they can perform better and more stably. At the same time, users don’t need to add booster pumps in the installation process, saving you installation costs! Technical cost!Maintenance cost!
Users can self-preset steam pressure and differential pressure as required. When the system detects that the steam pressure is less than the preset differential pressure, the equipment units burn incrementally group by group; When it is detected that the steam pressure is greater than the differential pressure, the equipment units will burn in descending order.
| Item/Model | Unit | LWZF*-0.7-Y(Q) | LWZF*-1.25-Y(Q) | |||||
| 0.2 | 0.3 | 0.5 | 0.75 | 1.0 | 1.2 | |||
| Heat input | KW | 50-150 | 150-300 | 150-450 | 150-600 | 150-750 | 150-750 | |
| Steam capacity | Kg/h | 60-200 | 200-400 | 200-600 | 200-800 | 200-1000 | 200-1000 | |
| Steam temperature | ℃ | 100-216 | 100-216 | 100-216 | 100-216 | 100-216 | 100-216 | |
| Steam pressure | MPa | 0.1-1.2 | 0.1-1.2 | 0.1-1.2 | 0.1-1.2 | 0.1-1.2 | 0.1-1.2 | |
| Nitrogen oxides(Low nitrogen type) | mg/m³ | ≦30 | ≦30 | ≦30 | ≦30 | ≦30 | ≦30 | |
| Rated combustion gas pressure | Natural gas | Pa | 2000 | 2000 | 2000 | 2000 | 2000 | 2000 |
| LPG | Pa | 2800 | 2800 | 2800 | 2800 | 2800 | 2800 | |
| Combustion gas(Natural gas) | Nm³/h | 14.7 | 14.7-29.4 | 14.7-44.1 | 14.7-58.8 | 14.7-73.5 | 14.7-73.5 | |
| Applicable to the power supply | AV220/50Hz | AV220/50Hz | AV220/50Hz | AV220/50Hz | AV220/50Hz | AV220/50Hz | ||
| Maximum power consumption | W | 650 | 880 | 1900 | 2150 | 2450 | 2450 | |
| Thermal efficiency | 98-102% | 98-102% | 98-102% | 98-102% | 98-102% | 98-102% | ||
| Exhaust smoke temperature | ℃ | ≦65 | ≦65 | ≦65 | ≦65 | ≦65 | ≦65 | |
| Waterproof level | IP×4 | IP×4 | IP×4 | IP×4 | IP×4 | IP×4 | ||
| Dimensions(Length**) | mm | 920*2180*1316 | 920*2400*1740 | 1210*2560*1740 | 1210*2560*1745 | 1210*2560*2450 | 1210*2560*2450 | |
| Steam outlet/water inlet pipe | DN25/DN20 | DN40/DN25 | DN40/DN25 | DN40/DN25 | DN40/DN25 | DN40/DN25 | ||
| Gas mouth/condensate water pipe | DN40/DN15 | DN40/DN15 | DN65/DN15 | DN65/DN15 | DN65/DN15 | DN65/DN15 | ||
| Circulating inlet and outlet pipe | DN40/DN40 | DN40/DN40 | DN65/DN65 | DN65/DN65 | DN65/DN65 | DN65/DN65 | ||
| Exhaust smoke pipe | DN200*3 | DN200*3 | DN200*3 | DN200*3 | DN200*3 | DN200*3 | ||
